Capacity 3KVA / 2700W

INPUT:

Rated voltage - 208v / 220v / 230v / 240v

Voltage Range - 110~176 Vac (liner derating between 50% and 100% load), 176~280 Vac ( no derating), 280~300 Vac (dearating 50%)

Frequency - 40 ~ 70 Hz (auto - sense)

Power Factor > 0.99

Bypass voltage - -25% ~ +15% (settable)

OUTPUT

Voltage -  208v / 220v / 230v / 240v

Voltage regulation - + - 1%

Frequency - 45~55 Hz or 55~65 Hz (synchronized rage) : 50 / 60 Hz

Waveform - Sinusoidal

Crest factor - 3:1

Harmonic distortions - 2% Linear load: 5% non linear load

Transfer time - main mode to battery mode : 0 ms, inverter mode to bypass mode: 4 ms (typical)

Overload capacity - 105% ~ 125%: transfer to bypass in 1min;, 125% ~ 150% transfer to bypass in 30s;, 150% transfer to bypass in 300 ms

EFFICIENCY

Main mode - 91%

Battery Mode - 86%

ECO Mode - 96%

BATTERIES

12v / 9 Ah
